Logging Rope
Regular Logging Rope
Rope Diameter
(inch)
Metric
(mm)
Construction
Min. Breaking Load
(Tones)
Weight per meter
(Kg)
Application
-
9.0
6x19 IWRC
5.20
0.35
Straw line
-
10.0
6x19 IWRC
6.42
0.43
Straw line
7/16
11.2
6x19 IWRC
7.77
0.54
Straw line
1/2
12.7
6x19 IWRC
10.80
0.73
Tag line
9/16
14.3
6x19 IWRC
12.60
0.88
Small Tail line
5/8
16.0
6x26 IWRC
16.42
1.10
Tail line, Strops line
3/4
19.0
6x26 IWRC
23.15
1.55
Main line, Tail line, Strops line
7/8
22.2
6x26 IWRC
32.22
2.13
Main line, Tail line, Strops line
1
25.4
6x26 IWRC
43.44
2.78
Main line, Sky line, Guy line
1-1/8
28.6
6x19 IWRC
52.56
3.52
Sky line, Guy line
1-1/4
31.8
6x25 IWRC
65.77
4.35
Sky line, Guy line
1-3/8
35.0
6x25 IWRC
78.72
5.27
Sky line, Guy line
Swaged Logging Rope
Rope Diameter
(inch)
Metric
(mm)
Construction
Min. Breaking Load
(Tones)
Weight per meter
(Kg)
Application
1/2
12.7
6x26 IWRC
14.48
0.88
Main line, Tail line
9/16
14.3
6x26 IWRC
18.33
1.07
Main line, Tail line
5/8
16.0
6x26 IWRC
21.72
1.30
Main line, Tail line
11/16
17.5
6x26 IWRC
27.15
1.55
Main line, Tail line
3/4
19.0
6x26 IWRC
31.31
1.82
Main line, Tail line, Sky line
7/8
22.2
6x26 IWRC
42.62
2.75
Main line, Tail line, Sky line
1
25.4
6x26 IWRC
55.78
3.48
Main line, Sky line, Guy line
1-1/8
28.6
6x26 IWRC
63.94
4.30
Sky line, Guy line
1-1/4
31.8
6x26 IWRC
78.93
5.21
Sky line, Guy line
*the “Application” information in the tables is offered only as a guide.
Minimum Order Quantity: 1000meters
